TP-LINK Switch 16x1000Mbps (POE+) + 2xGigabit SFP Fémházas Rackes, DS1018GMP

Name: TP-LINK Switch 16x1000Mbps (POE+) + 2xGigabit SFP Fémházas Rackes, DS1018GMP
Brand: TP-LINK
SKU: 356530
Price: 131490 HUF
Availability: InStock

Cikkszám:

356530

TP-LINK Switch 16x1000Mbps (POE+) + 2xGigabit SFP Fémházas Rackes, DS1018GMP

Raktáron

TP-LINK Switch 16x1000Mbps (POE+) + 2xGigabit SFP Fémházas Rackes, DS1018GMP

Gyártó:

TP-LINK

Garancia:

60 hónap

További adatok

131 490 Ft

Részletek

HARDWARE FEATURES
Standards and Protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3z, IEEE 802.1p
Interface	• 16× 10/100/1000 Mbps PoE+ RJ45 ports • 2× Combo Gigabit SFP slots
Network Media	• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 1000BASE-X MMF, SMF
Fan Quantity	2
Physical Security Lock	Yes
Power Supply	100–240 VAC, 50/60 Hz
PoE+ Ports(RJ45)	• Standard: 802.3at/802.3af compliant • PoE Ports: Ports 1–16 • PoE Power Budget: 250 W
Dimensions ( W x D x H )	17.3 × 7.1 × 1.73 in (440 × 180 × 44 mm)
Mounting	Rack Mountable
Max Power Consumption	• 19 W (220/50 Hz. no PD connected) • 293.34 W (220/50 Hz. with 250 W PD connected)
Max Heat Dissipation	• 64.79 BTU/h (no PD connected) • 1000.29 BTU/h (with 250 W PD connected)

PERFORMANCE
Switching Capacity	36 Gbps
Packet Forwarding Rate	26.78 Mbps
MAC Address Table	8K
Packet Buffer Memory	4.1 Mbit
Advanced Functions	• Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode: Ports 1–4** • Priority Mode: Ports 1–4 • Isolation Mode: Ports 1-8/9-16 • PoE Auto Recovery: Ports 1-16 • Mac Address Auto-Learning and Auto-Aging • 802.1p/DSCP QoS • IEEE802.3x Flow Control
Jumbo Frame	10 KB

OTHERS
Certification	CE, FCC, RoHS
Package Contents	• DS1018GMP • Installation Guide • Power Cord • Rackmount Kit • Rubber Feet
Environment	• Operating Temperature: 0–50 °C (32–122 °F) • Storage Temperature: -40–70 °C (-40–158 °F) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing

Adatok

Gyártói cikkszám:

DS1018GMP

EAN:

4895252507782

Gyártó:

TP-LINK

EAN:

4895252507782

Rack-be szerelhető:

Van

Switch típus:

Modular

Menedzselhetőség:

Nem menedzselhető

Portok száma:

Port típusa:

1Gb Réz

Switching kapacitás:

Menedzselhető:

Nincs

PoE (Power over Ethernet):

Van

Áteresztő képesség:

26,78

SFP port:

Tömeg:

3,15 kg/db
